Aluminum Demountable Partition Wall Installation Guide with Video

Brand Name : Glawall

Model Number : every style (framed/frameless) double glass

Certification : SGS, ISO 9001,UL, CE

Place of Origin : China

MOQ : 10 square maters

Price : US$80.00 10 - 99 square meters

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Supply Ability : 3000 square maters per month

Delivery Time : 25 days

Packaging Details : plywood

Material : Aluminum Frame

Transparency : Clear

factory Certification : Yes

factory area : 20000 square meter

Customizable : size, accessories

Competitive price : yes

Glass Thickness : 5mm,6mm, 10mm, 12mm

Advantage : Competitive price, good service, high professional, quality guarantee

Warranty : 2 Years

Contact Now

Aluminum Demountable Partition Wall Installation Guide with Video


Professional Installation Process for Demountable Partition Walls
Demountable partition walls offer flexibility, speed, and precision in space division—whether for offices, co-working spaces, or commercial interiors. Our streamlined installation process ensures seamless assembly, structural integrity, and a flawless finish.


Step-by-Step Installation Guide


1. Planning & Design ✔ Space Assessment Measure floor plans, ceiling height, and load-bearing requirements
✔ Custom Layouts Optimize wall placement for privacy, acoustics, and traffic flow
✔ Material Selection Choose glass, aluminum, or hybrid panel systems
2. Site Preparation Floor & Ceiling Inspection Ensure level surfaces (±2mm tolerance)
Clearance & Safety Remove obstacles, mark electrical/plumbing zones
Modular Grid Mapping Laser-guided alignment for track positioning
3. Track Installation Heavy-Duty Aluminum Channels Anchored to ceiling/floor with seismic-rated brackets
Precision Leveling Adjustable shims compensate for uneven surfaces
Load Testing Verified to support 200kg/m² vertical loads


Aluminum Demountable Partition Wall Installation Guide with Video



4. Panel Assembly ✔ Pre-Assembled Modules Glass or solid panels slide into tracks (no welding/gluing)
✔ Acoustic Seals Silicone gaskets reduce sound transmission by 5-8dB
✔ Tool-Free Adjustments Cam-lock system enables millimeter-perfect alignment
5. System Integration Doors & Operable Walls Pivot/sliding doors installed with auto-latching hardware
Cable Management Integrated wire channels for power/data
Hybrid Attachments Compatible with whiteboards, shelving, or green walls
6. Quality Assurance Laser Alignment Check Ensures walls are plumb (±1.5mm variance)
Operational Testing Doors, moving parts, and acoustic seals verified
Client Walkthrough Final inspection with sign-off protocol


Aluminum Demountable Partition Wall Installation Guide with Video


Installation steps


  • Paetition up the celling
  • Wall starter installation
  • Celling connection installation
  • Bottom connection installation
  • Conner pole installation
  • Horizontal panel
  • Vertical panel
  • Bind panel

Wall starter installation & vertical adjustment
Regulate the vertical adjusting pole tothe vertical position by the M8*30bolt,and fix it with the side groove byself-tapping screw

Top and bottom groove installation&vertical
Vertical adjusting pole should be samecenter line with top and bottom groove

  • Corner pole installation
  • Horizontal panels connection
  • Vertical panels connection
  • Blind installation

Aluminum Demountable Partition Wall Installation Guide with Video


Each model has a different installation method. We'll provide detailed instructions in PDF format and a video tutorial.
Please contact us to start a chat!~


Aluminum Demountable Partition Wall Installation Guide with Video
